Now users can program their applications using logical names for devices, and reference those values from the GOT1000 HMI.SAFETY PRECAUTIONS (Always read these instructions before using this product.) Before using this product, thoroughly read this manual and the relevant manuals introduced in this manual and pay careful attention to safety and handle the products properly The precautions given in this manual are concerned with this product For the safety precautions of the programmable controller system, refer to the User's Manual for the CPU module In this manual, the safety precautions are ranked as " WARNING" and " CAUTION" WARNING Indicates that incorrect handling may cause hazardous conditions, resulting in death or severe injury CAUTION Indicates that incorrect handling may cause hazardous conditions, resulting in minor or moderate injury or property damage Note that the CAUTION level may lead to serious consequences according to the circumstances Always follow the precautions of both levels because they are important for personal safety Please save this manual to make it accessible when required and always forward it to the end user WARNING
TRACE FUNCTION MELSOFT GX WORKS2 SOFTWARE
Simulators and additional configuration software have been integrated into the base software, and Label programming across the entire system has been implemented. This next generation software provides a fully customisable user friendly environment with the developers in mind.
TRACE FUNCTION MELSOFT GX WORKS2 SERIES
GX Works 2 is one of four parts of Mitsubishi Electric’s iQ Works intuitive software suite for programming and setup of an iQ Platform system, including system/network configuration, Q and FX Series programming, Q Motion Controller and Servo setup, GOT1000 HMI screen design. A built-in virtual PLC on the computer enables complete system simulation before hardware even arrives on site.Īfter the project is downloaded to the actual system, GX Works2 includes numerous monitor modes, trace functions, and online debugging capabilities to put the finishing touches on the application and speed it to commission status. Special function module parameters are setup using prompts and pull-down menus, not through arbitrary bit and byte assignments. Completely customisable environment layouts follow the installation and not the project, meaning tool selection and shortcuts are optimised following the user’s own intuition.īuilt-in network and special function module configuration tools keep project files organised and easy to access. That means once a function, function block, program, or structure is written, tested, and proven, and it can be integrated into new systems within minutes. This environment conforms to IEC1131-3 standards, also allowing parts of projects to be saved in Libraries for use within future applications.
It is left up to the developer to select the language most comfortable and best suited for the job. GX Works2 allows developers to mix and match between five different programming languages, each conforming to a different programming style. Its functionality has been inherited from both GX and IEC Developer, with improvements made throughout to increase productivity and drive down engineering costs. GX Works2 is the next generation configuration and programming software for Mitsubishi FX and Q Series controllers and it is available with a saving of £729 from 999Mitsubishi.
